PROPERTIES CROSS generate pulses of over-unity ENERGY
Victor Litvinov
It is well known that there is no perpetual motion, and by definition, science can not be. The law of conservation of energy is unshakable. In any mechanical device ideally resulting sum force after any changes, the output device, eventually vanishes. In any generator or energy converter, the output power can not be higher than the initial power. In the real device output power is less than the input by counteracting the forces of friction.
SUMMARY opening lies in that a device consisting of two crosses (diagonal squares) planted on the axis of rotation interconnected by chain or rope having a secure grip with crosses in rotation crosses able to generate pulses of excess capacity or over-unity energy with an exemplary efficiency of 110% per device.
Using my discovery can design and produce mechanical power multiplier, which to multiply the power can be connected in series, and using which a person can muscle force to propel any mechanical device to which you want to drive a large power, such as a car.
My discovery proves conclusively the close relationship between science and religion, it proves the existence of the cross, not only spiritual power, but also physical.
The cross - a symbol of eternity. My discovery proves the truth of the Christian faith, and is likely to lead to a rethinking of the Bible will eliminate its allegorical interpretation ..
My discovery will create a true perpetual motion machine - (perpetuum mobile), an inexhaustible source of energy, which, I believe, brought to Earth by Jesus Christ. Cross permanently solve the energy problems of mankind and significantly advance the scientific and technical progress.
SUMMARY opening lies in that a device consisting of two crosses planted on the axis of rotation interconnected by chain or rope, embracing them and having good traction with crosses in rotation crosses able to generate pulses of excess capacity or over-unity energy to an exemplary, average efficiency of 110% per device.
If you round a pulley arm the torque is constant, then the cross arm of the torque during rotation smoothly through 45 ° varies from a minimum, numerically equal to 1/2 of the cross side, up to a maximum equal to half the diagonal of the square, or the length cross blades.
It is found that two of the same cross, mounted on axes of rotation at any angular displacement on the axes relative to each other and associated flexible transmission freely rotate on axles, as well as round the pulleys connected in this way. Free spins and similar gear, consisting of a square and round a pulley. This is proof of a relatively uniform, almost linear chain movement in the square pulley.
Passing round the pulleys have the same, constant torque arm equal to the length of the perpendicular drawn from the axis of rotation of a line passing through the center of the pulley, the load to the point of suspension, or equal to a pulley radius.
|
Crosses with the same transmission, the pulleys or square, depending on the mutual angular position on the pulley axes can be variable, equally changing the torque shoulder (at zero angular displacement on the axes of pulleys square, 1, a, b.), Secondary the total value is equal to the torque at the shoulder round pulleys, or alternating, with angular displacement square pulleys 45 ° relative to each other (Figure 2).
|
|
Dynamics of changes in torque when rotating square pulleys (crosses), the offset on the axes by 45 ° relative to each - other can be understood from the figure (3 ad..). By connecting shafts pulleys 1 with the same stars, the rim of which is equal to the length of the perimeter of the square pulley, which is wearing the same chain and hung loads (the figure not shown), will start to rotate right pulley clockwise (Figure 3a). When a sufficient weight of cargo placed on the star, and minimum friction, we note that despite the fact that the loads are equal, the transmission, the position of the pulleys shown in FIG. 3a to the position of the pulley shown in Figure 3 b, moves itself under the weight of cargo. In this figure, the pulleys are in a stable equilibrium. Rotate the pulleys further clockwise, we find that the left pulley rotation has some resistance, increases with the angle of rotation (3c.), And with further rotation of the transmission, resistance decreases and there comes a delicate balance (Figure 3 d) . If the pulleys make one revolution, the above-described cycle is repeated 4 times. That is, a reduction of the cycle - the increase of the torque occurs at 90 ° rotation. Initially, one square is a reduction pulley and the other arm of the torque increase, then, upon further rotation of the device as if pulleys are interchanged, - reduction in the moment where it was - increase occurs where there was an increase in torque - occurs decrease. Were found in terms of differentiation of half cycles decrease - increase points - position belt pulleys corresponding to the position of these points are illustrated in FIG. 3b, 3d. This is the position of stable and unstable equilibrium that occur periodically, through a 45 ° rotation of the pulleys. |
It follows that if we continuously rotate transmission, the shaft alternately through 45 ° will appear positive and negative excess torque excessive torque increases from zero to a maximum value and decreasing again to zero.
|
With the help of known mechanical devices can be identified and removed from the PTO positive excess torque. If you draw a graph (Figure 4), reflecting changes in output, we obtain an infinite sequence of positive power pulses, increasing to a certain value, and is reduced to zero with respect to a certain level determined by the input power. The amplitude of these pulses will depend on the weight of the goods, or application of power and duration of the pulse will depend on the speed of rotation of the pulleys. Pulsation power pulses can be reduced by installing a flywheel on the shaft or the inertial mechanism. |
FORMULA DISCOVERY
It is found that a device consisting of two crosses planted on rotational axis being offset relative to each other on axes at 45 ° and connected by a chain or rope, embracing them and having good traction with crosses, upon application of forces to the axes and rotation crosses capable generate pulses of excess capacity, or over-unity energy with exemplary, the average efficiency of 110% on a single device, due to the change in mutually opposite forces moments shoulders on both crosses.
print version
Author: Victor Litvinov
PS material is protected.
Publication date 09.02.2005gg
